Description
Technical Specifications
Number of Screens: 1
Screen Size Class: 24inch
Viewable Screen Size: 23.8"
Screen Mode: Full HD
Panel Technology: Vertical Alignment (VA)
Response Time: 5 ms
Response Time Details
8ms GTG
5ms GTG (Fast)
Aspect Ratio 16:9
Pixel Pitch: 0.2745 mm x 0.2745 mm
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Mount Type: Panel Mount
Backlight Technology: Edge LED
HDCP Supported: Yes
Tilt Angle: -5° to 21°
Features
Eye Comfort Technology
Anti-glare
Narrow Bezel
Security Lock
Mercury-free
Cable Lock Slot
Arsenic-free Glass
Stand Adjustments: Tilt
Stand Included: Yes
Glass Hardness: 3H
Video
Maximum Resolution: 1920 x 1080
Standard Refresh Rate: 75 Hz
Color Supported: 16.7 Million Colors
Native Contrast Ratio: 3,000:1
Brightness: 250 cd/m2 (typical)
Color Gamut
83% NTSC (CIE 1976)
72% NTSC (CIE 1931)
Maximum Preset Resolution: 1920 x 1080 at 75Hz
Pixel Per Inch (PPI): 93
Interfaces/Ports
Connectivity
One HDMI (HDCP 1.4) (supports up to FHD 1920 x 1080 75Hz as per specified in HDMI 1.4)
One VGA connector
Audio Line Out: No
Environmental Conditions
Operating Temperature Range: 32°F (0°C) to 104°F (40°C)
Non-operating Temperature Range: -4°F (-20°C) to 140°F (60°C)
Operating Humidity Range: 10% to 80% (Non-condensing)
Non-operating Humidity Range: 5% to 90% (Non-condensing)
Maximum Operating Altitude: 16400 ft
Maximum Non-operating Altitude: 40000 ft
Power Description
Operating Power Consumption: 14.30 W
Standby Power Consumption: 300 mW
Off-Mode Power Consumption: 300 mW
Frequency
50 Hz
60 Hz
Maximum Power Consumption: 22 W
Voltage Current: 700 mAh
Physical Characteristics
VESA Mount Compatible: Yes
VESA Mount Standard: 100 x 100
Height: 13.1"
Width: 21.8"
Depth: 1.9"
Height with Stand: 16.55"
Width with Stand: 21.76"
Depth with Stand: 7.04"
Weight (Approximate) 6.17 lb
Weight with Stand (Approximate) 7.63 lb
Miscellaneous
Package Contents
SE2425H Widescreen LED Monitor
Stand
Quick Start Guide
Safety Information
Cables Included
1 x Power Cable
1 x HDMI Cable - 1.8 m
