Description
General
Display Type
LED-backlit LCD monitor / TFT active matrix
Energy Class
Class B
Energy Consumption per Year
63 kWh
Power Consumption (On mode)
43 W
Diagonal Size
32"
Viewable Size
31.5"
Built-in Devices
USB 3.0 hub
Panel Type
IPS
Aspect Ratio
16:9
Native Resolution
4K 3840 x 2160 at 60 Hz
Pixel Pitch
0.182 mm
Pixel Per Inch
140
Brightness
400 cd/m²
Contrast Ratio
1300:1
Color Support
1.07 billion colors
Response Time
8 ms (normal); 5 ms (gray-to-gray)
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Screen Coating
Anti-glare, 3H Hard Coating
Backlight Technology
LED backlight
Features
LED edgelight system, 99% sRGB color gamut, BFR/PVC-free, Infinity Edge display, 99% Rec 709 color gamut, DCI-P3 95% color gamut
Dimensions (WxDxH)
28.1 in x 8.7 in x 18.5 in - with stand
Preset Display Area (H x V)
392.2 mm x 697.3 mm
15.44" x 27.45"
273505.9 mm2 (423.93 inch2)
Border Width (Edge of Monitor active area)
7.6 mm (Top/Left/Right)
14.7 mm (Bottom)
Viewing Angle
178° (vertical) typical
178° (horizontal) typical
Pixel Per Inch (PPI)
140
Wireless Charging Feature
NA
G-SYNC Support
NA
PbP / PiP
Yes
Daisy Chain Availability
No
Dell Display Manager Compatibility
Yes
Remote Asset Management
Yes, via Dell Command |Monitor
Specifications - Service / Support Details
3-Year Advanced Exchange Service and Premium Panel Exchange
Color Calibration SDK SW
No
Color Calibration with X-rite colorimeter
No
Height without stand
414.5 mm
16.32",No"
Width without stand
712.5 mm
28.05",No"
Depth without stand
44.5 mm
1.75",No"
Weight (with packaging)
13.3 kg
29.3 lb
Built-in Devices
1 x USB Type-C port, 1 x USB 3.0 upstream port, 4 x USB 3.0 downstream ports
Security
Security lock slot (cable lock sold separately)
Flat Panel Mount Interface
VESA (100 mm x 100mm)
Temperature Range
Operating: 0° to 40°C (32° to 104°F)
Non-operating: -20° to 60° (-4° to 140° F)
Humidity Range
Operating: 20% to 80% (non-condensing)
Non-Operating:10% to 90% (non-condensing)
Altitude
Operating: 5,000 m (16,404 ft) max
Non-Operating: 12,192 m (40,000 ft) max
Voltage Required
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A (typical)
Power Consumption (Operational)
46 W (typical) / 230 W (maximum)**
** Maximum power consumption with max luminance and contrast.
Power Consumption Stand by / Sleep
0.5W
What's Included
Monitor, Stand Riser and Stand Base
Power cable
1 x DP to DP Cable
1x USB Type-C Cable (C to C)
1x USB.30 Upstream Cable
Quick Setup Guide
Factory Calibration Report
Safety and Regulatory Information
Connectivity
Interfaces
- USB-C upstream/DisplayPort with Power Delivery
- HDMI (HDCP)
- DisplayPort
- 2 x USB 3.0 downstream with Battery Charging 1.2
- 2 x USB 3.0 downstream
- USB 3.0 upstream
Mechanical
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Tilt Angle
-5/+21
Swivel Angle
60
Rotation Angle
180
Height Adjustment
5.9 in
VESA Mounting Interface
Yes
Miscellaneous
Features
Security lock slot (cable lock sold separately)
Cables Included
- Power cable
- DisplayPort cable
- USB-C cable (C to C)
- USB 3.0 Upstream cable
Compliant Standards
ENERGY STAR certified monitor
EPEAT registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by country
RoHS-compliant
TCO certified displays
BFR/PVC free monitor (excluding external cables)
Arsenic-free glass and Mercury-free for the panel only
Security Slot Type
Kensington security slot
Power
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
46 Watt
Power Consumption Stand by
0.5 Watt
Power Consumption Sleep
0.5 Watt
Dimensions & Weight
Dimensions & Weight Details
- With stand - width: 28.1 in - depth: 8.7 in - height: 18.5 in
- Without stand - width: 28.1 in - depth: 1.8 in - height: 16.3 in - weight: 12.8 lbs
Dimensions & Weight (Shipping)
Shipping Weight
29.32 lbs
Environmental Standards
TCO Certified
TCO Certified Displays 8
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Bundled Services
3-Years Advanced Exchange Service and Premium Panel Guarantee
Environmental Parameters
Min Operating Temperature
32 °F
Max Operating Temperature
104 °F
Humidity Range Operating
20 - 80% (non-condensing)
