Description
TECH SPECS
Specifications Scanner:
Scanner Type:
Sheet-fed, one-pass duplex color scanner
Photoelectric Device:
CMOS single-line contact image sensor
Optical Resolution:
600 dpi
Color Bit Depth:
48-bits per pixel internal / 24-bit external
Monochrome Bit Depth:
1-bit
Grayscale Bit Depth:
16-bits per pixel internal / 8-bit external
Output Resolution:
75 to 1200 dpi
Effective Pixels:
5,100 x 21,600 pixels
Light Source:
3-Color RGB LED
Scanning Speed:
up to 26 ppm/52 ipm1
Scan Features:
Buttons:
3 buttons: Power, Start, and Stop
Power:
Rated Voltage:
100 â 240 VAC
Rated Frequency:
50 â 60 Hz
Power Consumption:
Normal mode: 18 W
Ready mode: 7 W
Sleep mode: 1.6 W
Off: 0.4 W
Automatic Document Feeder:
Capacity:
50 sheets
Document Sizes:
Paper size Minimum: 2.1-in x 2.9-in
Paper size Maximum: 8.5-in x 36-in
Daily Duty Cycle:
3,000 sheets
Paper Weight:
50 to 209 g/m
Consumables:
Roller assembly kit: 100,000 cycles
General:
Operating Systems:
Windows 10
Windows 8/8.1
Windows 7
Mac OS X 10.9.8 â macOS 10.12.x
Software requires Internet connection for download and installation.
Temperature:
4 to 95 F (10 to 35 C)
Humidity:
10 â 80% (no condensation)
Dimensions:
11.7-in x 6-in x 6.1-in (W x D x H)
Weight:
5.5 lb
Connectivity:
Standard Connectivity:
Hi-Speed USB 2.0
Scanner Details:
Included Software:
Epson Scan
OpenText Captiva ISIS (Windows only, via web download)
Document Capture Pro
TWAIN and ISIS drivers
