Description
Technical Specifications
Dimensions and Weight:
Dimensions (W x D x H): 296 x 104 x 125 mm
Weight: 1.8kg
Environmental Conditions:
Temperature:
Operating: 5 - 35 °C
Storage -25 - 60 °C
Humidity:
Operating 15 - 80 % (No Condensation)
Storage 15 - 85 % (No Condensation)
Options:
Carrier Sheet:
Durability: 3,000 scans
Order Code: B12B819051
Scanner:
Scanner Type:
A4 sheet-fed, one-pass duplex colour scanner
Sensor Type:
Colour Contact Image Sensor (CIS) x 2
Scanning Method:
Fixed carriage and moving document
Light Source:
RGB LED x 2
Optical Resolution *1:
600 x 600 dpi
Output Resolution:
50 ? 1,200 dpi (in 1 dpi increments)
Bit Depth:
Colour: 30-bit input, 24-bit output
Grayscale: 10-bit input, 8-bit output
Black and White: 10-bit input, 1-bit output
Document Size:
Minimum 50.8 x 50.8 mm
Maximum 215.9 x 3,048 mm
Supported Paper Weight:
Vertical Path: 40 ? 127 g/m2 , Less than A6 size: 40 ? 209 g/m2
Straight Path: 40 ? 413 g/m2
ADF Capacity:
20 sheets (80 g/m2 )
Daily Scan Volume:
Up to 5,000 sheets / day
Multi-feed Detection:
Length Detection
Interface:
USB 2.0
