Description
Technical Specifications
Interface: PCIe 3.0x4, NVMe1.3 interface
Form Factor: M.2 2280
Total Capacity: 500GB
External DDR Cache: N/A
Sequential Read speed Up to 2300 MB/s
Sequential Write speed Up to 1500 MB/s
Random Read IOPS Up to 60K
Random Write IOPS Up to 240K
Dimension 22 x 2.3 x 80 mm
Mean time between failure (MTBF) 1.5 million hours
Max. Operating Power:
Read: 2300mW
Write: 2250mW
Power Consumption (Idle, PS3) 30mW
Power Consumption(PS4, L1.2) 5mW
Temperature (Operating) 0°C to 70°C
Temperature (Storage) -40°C to 85°C
