Description
Specifications
CPU
AMD Ryzen 7 7730U Processor, AMD Ryzen 7000 Series, 8 Cores, 16 Threads, 2.0GHz Base Frequency, Up to 4.5GHz Boost, 4MB L2 Cache, 16MB L3 Cache, TSMC 7nm Process
CPU Package
FP6 Package, TSMC 7nm FinFET
Graphics
AMD Radeon Graphics, 8 Compute Cores, Up to 2000MHz
Memory
2x 8GB = 16GB DDR4 3200, 2x SO-DIMM Slots, Supports Up to 64GB
Storage
512GB M.2 2280 PCIe 3.0 SSD
Storage Expansion
2x M.2 2280 SSD Slots, Supports Up to 8TB per SSD (Up to 16TB Total)
Graphics Output
Triple Display Support via HDMI, DisplayPort, and USB-C, Supports Up to 8K Resolution via DisplayPort
Network
Wi-Fi 6E (RZ616, Up to 2.4Gbps), Bluetooth 5.2, Dual 2.5G Ethernet LAN
USB Ports
2x USB 3.2 Gen2 (10Gbps), 2x USB 2.0
USB-C Port
1x USB 3.2 Gen2 Type-C with DisplayPort 1.4, 100W Power Delivery, Up to 4K@60Hz
HDMI Port
1x HDMI 2.0 (Up to 4K@60Hz)
DisplayPort
1x DisplayPort 1.4 (Up to 8K@60Hz)
Audio
1x 3.5mm CTIA Audio Jack
LAN
2x RJ45 2.5G Ethernet Ports
Power
DC IN (19V/3.42A), Built-in Coin Cell Battery
Reset Button
1
Operating System
Windows 11 Pro
Language Support
English, Simplified Chinese, Traditional Chinese, French, Dutch, Italian, Spanish, Korean, Japanese, German, Hebrew, Russian, Portuguese, Arabic
Dimensions
128.8 × 127 × 47.8 mm
Weight
28g
Color
Rust Color
Operating Temperature
0°C to 40°C
Certifications
CCC, CE, FCC, RoHS, MIC, CEC, China Energy Label, UL Report
Package Contents
User Manual, Warranty Card, Power Adapter, VESA Mount Bracket, HDMI Cable
