Description
Technical Specifications
Design + Dimensions
Dimensions (W x H x D) (mm) 71.8 W x 50.8 H x 33.6 D (mm)
Weight (Camera w/mounting fingers + Embedded Battery)
154g (Camera w/mounting fingers + Battery)
121g (Without Battery)
Battery: Removable 1900mAh Enduro Battery
Displays: Rear: 2.27" Touch Display
Front: 1.4" Color Display
Rugged + Waterproof: 10m (33ft)
Mounting
Built-In Mounting with Folding Fingers
¼-20 Mount
Removable Water-repelling Cover Glass: Yes
Memory Storage microSD: 1 microSD? with at least V30 or higher UHS-3 rating
Connector: USB-C
HDMI Port: Media Mod (H9B/H10B/H11B/H12B)
Operating Temperature: -10º C - 35º C
Image Quality / Hardware Spec
System Processor: GP2
Image Sensor
1/1.9" CMOS
27.6 MP active pixels (5599x4927)
Lens Aperture: F2.5
35mm Equivalent Focal Length
Min = 12mm
Max = 39mm
Video
Video Resolutions & Frame Rates
5.3K (8:7) 30/25/24 fps
5.3K (16:9) 60/50/30/25/24 fps
4K (8:7) 60/50/30/25 fps
4K (9:16) 60/50/30/25
4K (16:9) 120/100/60/50/30/25/24 fps
2.7K (4:3) 120/100 fps
2.7K (16:9) 240/200 fps
1080 (9:16) 60/50/30/25
1080p (16:9) 240/200/120/100/60/50/30/25/24 fps
Video Stabilization: HyperSmooth 6.0
Aspect Ratio: 16:9 9:16 4:3 8:7
HDR Video
5.3K (16:9) 30/25/24 fps
4K (8:7) 30/25/24 fps
4K (16:9) 60/50/30/25/24 fps
Digital Lenses
HyperView
SuperView
Wide
Linear
Linear + Horizon Lock / Leveling
360 Horizon Lock & Horizon Leveling
Lock: Linear + Horizon Lock Lens
Leveling: In-Camera (23-27*) for 5.3K60; 4K120; 2.7K240; 1080p240
Can apply in post using Quik App
Video Compression Standard: H.265 (HEVC)
Color Video Bit Depth
8-bit
10-bit (4K and higher)
Maximum Video Bit Rate: 120Mbps
Zoom (Video): Up to 2x
Slo-Mo
8x - 2.7K; 1080p
4x - 4K
2x - 5.3K
Burst Slo-Mo
13x (400fps) - 720p for 15s
12x (360fps) - 900p for 15s
4x - 5.3K for 5s
Looping Video: Yes
HindSight: Yes
Scheduled Capture: Yes
Duration Capture: Yes
Live Streaming: 1080p60 w/HyperSmooth 4.0 + 1080p60 recording
Webcam Mode: up to 1080p30
Timecode Synchronization: Yes
Exposure Control: Yes
Exposure Value (EV Comp) 2+/-
Photo Modes
Standard Photo
Burst Photo
Night Photo
Max Photo Resolution: 27.13MP (5568x4872)
Photo Frame-Grabs from Video
24.69MP from (8:7) 5.3K Video
21.16MP from (4:3) 5.3K Video
15.87MP from (16:9) 5.3K Video
Photo Output: Super
Photo, HDR, Standard, RAW
Photo Formats
.jpg
.gpr (RAW)
RAW Photo Capture: 27.13MP (5568x4872)
Digital Lenses (single photo)
Wide
Linear
Photo Timer: 3s, 10s
Photo Intervals: 0.5s, 1s, 2s, 3s, 5s, 10s, 30s, 60s, 120s
Burst Photo Rates (Frames / Second): Auto, 60/10, 60/6, 30/6, 30/3, 10/3, 30/1, 10/1, 5/1, 3/1
Night Photo Shutter Speed: Auto, 2, 5, 10, 15, 20, 30 sec.
TimeWarp Video: TimeWarp 3.0 (up to 5.3K)
TimeWarp Video Speeds: Auto, 2x, 5x, 10x, 15x, 30x
Star Trails: Yes
Light Painting: Yes
Vehicle Light Trails: Yes
Time Lapse Video Resolution Up to 5.3K
Time Lapse Intervals (Video & Photo)
0.5, 1, 2, 3, 5, 10, 30, 60 sec.;
2, 5, 30, 60 min.
Night Lapse Video Resolution Up to 5.3K
Night Lapse Intervals (Video & Photo)
Auto, 4, 5, 10, 15, 20, 30, 60 sec.;
2, 5, 30, 60 min.
Audio Features
Microphones: 3-mics
Stereo Audio: Yes
Advanced Noise Reduction: 3-mic Processing
RAW Audio Capture: WAV Format
3.5 Audio Mic Input
Media Mod (H9B/H10B/H11B)
Pro 3.5mm Mic Adapter
Wireless Audio: Support Airpods and other bluetooth headsets
Connected Features
Wi-Fi Frequency: Wi-Fi 6; 2.4GHZ; 5GHz
Wi-Fi Protocol: 802.11 a/b/g/n/ac
Bluetooth: BLE 5.3
USB Port: USB-C
Mobile App Connection: Quik App
Auto Upload to Cloud: w/GoPro Subscription
User Interface
Protune: Yes
Presets / Custom Presets: Yes
Voice Control
14 Commands
11 Languages with 6 accents
Post-Capture UX
Advanced Metadata: Yes
Eco-system Support: Quik App GoPro Labs Open GoPro
Key Accessories
Remote Control
The RemoteWaterproof Shutter Remote
Volta
Quik App
Compatible Housing / Accessories
Protective Housing
