Description
Technical Specifications
Processor: Intel® Core i3-1315U, 6C (2P + 4E) / 8T, P-core 1.2 / 4.5GHz, E-core 0.9 / 3.3GHz, 10MB
Graphics: Integrated Intel® UHD Graphics
Chipset: Intel® SoC Platform
Memory: 8GB SO-DIMM DDR5-5200
Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 16GB DDR5-5200
Storage : 1TB SSD M.2 2280 PCIe® 4.0x4 NVMe®
Optane Memory: None
Storage Support: One drive, up to 1TB M.2 SSD
Card Reader: None
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek® ALC233-CG codec
Speakers: 3Wx2, HARMAN
Camera : 5.0MP + IR
Microphone: Dual Microphone
Power Supply: 90W 89% Adapter
DESIGN
Display: 23.8inch FHD (1920x1080) IPS Anti-glare 250nits, 100Hz, 99% sRGB, hardware low blue light, 3-side borderless, non-touch
Touchscreen: None
Keyboard: USB Calliope Keyboard, Black, English
Mouse: USB Calliope Mouse, Black
Expansion Slots : Two M.2 slots (one for WLAN, one for SSD)
Case Color: Luna Grey
Stand: AIO Stand
Wireless Charger: None
Pen: Pen Not Supported
Form Factor: AIO (23.8 inches)
Dimensions (WxDxH) 540 x 192 x 431 mm (21.25 x 7.56 x 16.97 inches)
Weight Around 6.0 kg (13.23 lbs)
CONNECTIVITY
Ethernet -
WLAN + Bluetooth Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN Non-WWAN
Ethernet: Integrated 100/1000M
Rear Ports
1x USB-A (USB 10Gbps / USB 3.2 Gen 2)
2x USB-A (Hi-Speed USB / USB 2.0)
1x HDMI®-in 1.4
1x HDMI®-out 2.1 TMDS
1x Ethernet (RJ-45)
1x power connector
Left Ports
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only
1x headphone / microphone combo jack (3.5mm)
SECURITY & PRIVACY
Security Chip" Firmware TPM 2.0 integrated in SoC
Physical Locks: No physical locks
SERVICE
Warranty: 3Y Premium Care - Idea AIO (ESS)
CERTIFICATIONS
Green Certifications
ENERGY STAR® 8.0
ErP Lot 3/7
GREENGUARD®
RoHS / WEEE / REACH
Other Certifications
TÜV Rheinland® Flicker Free
TÜV Rheinland® Low Blue Light
TÜV Rheinland® Ultra Low Noise
SOFTWARE
Operating System: Windows® 11 Home Single Language, English
Bundled Software: Office Home 2024
