Description
FREE: Pre installed Office Home 2024 + Lenovo® AI Now and Gaming bag
PERFORMANCE
AI PC Category: AI-Powered Gaming PC
Processor: Intel® Core i7-14700HX, 20C (8P + 12E) / 28T, P-core 2.1 / 5.5GHz, E-core 1.5 / 3.9GHz, 33MB
Graphics: NVIDIA® GeForce RTX™ 5070 8GB GDDR7, Boost Clock 2347MHz, TGP 115W, 798 AI TOPS
Chipset: Intel® HM770 Chipset
Memory: 24GB SO-DIMM DDR5-4800 (2x 12GB SO-DIMM DDR5-4800)
Memory Slots: Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR5-4800 offering
Storage: 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Max Storage Support: Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
Storage Slot: Two M.2 2280 PCIe® 4.0 x4 slots
Card Reader: None
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers: Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Camera: 5.0MP with E-shutter
Microphone: 2x, Array
Battery: 80Wh
Power Adapter: 245W Slim Tip (3-pin)
Special Features: AI Chip: LA1
DESIGN
Display: 15.1" WQXGA (2560x1600) OLED 500nits glossy, 100% DCI-P3, 165Hz, Dolby Vision®, DisplayHDR™ True Black 600
Color Calibration: Factory Color Calibration
Keyboard: 24-Zone RGB Backlit, English
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Case Color: Eclipse Black
Surface Treatment: Aluminium Stamping (Anodized with Sandblasting)
Case Material: Aluminium (Top), PC-ABS + 15% Talc (Bottom)
Dimensions (WxDxH): 344.9 x 255.35 x 19.95-21.54 mm (13.58 x 10.05 x 0.79-0.85 inches)
Weight: Starting at 1.9 kg (4.19 lbs)
SOFTWARE
Operating System: Windows® 11 Home Single Language, English
Bundled Software: Office Home 2024 + Lenovo® AI Now
CONNECTIVITY
WLAN + Bluetooth Wi-Fi® 7, 802.11be 2x2 + BT5.4
WWAN Non-WWAN
Ethernet 100/1000M (RJ-45)
Standard Ports 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x Power connector
- -
Docking: Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion 5 15IRX10
SECURITY & PRIVACY
Security Chip Firmware TPM 2.0 Enabled
Fingerprint Reader None
Other Security E-shutter
SERVICE
Base Warranty 1-year, Courier or Carry-in
Included Warranty Upgrade 3Y Legion Ultimate Support -IPMAIN (ESS)
CERTIFICATIONS
Green Certifications ErP Lot 6/26
- RoHS compliant
Other Certifications TÜV Rheinland® Flicker Free
- TÜV Rheinland® Low Blue Light (Hardware Solution)
