Model
ViewSonic VA24G1-H
Display
Display Size: 24" Viewable Area: 23.8" Panel Type: IPS Technology Resolution: 1920 × 1080 Resolution Type: FHD (Full HD) Aspect Ratio: 16:9 Curvature: Flat Refresh Rate: 144Hz Response Time (MPRT): 1ms Static Contrast Ratio: 1,500:1 (typ) Dynamic Contrast Ratio: 50M:1 Brightness: 400 cd/m² (typ) Light Source: LED Colors: 16.7M Color Space Support: 8 bit (6 bit + FRC) Viewing Angles: 178º horizontal, 178º vertical Backlight Life: 30000 Hrs (Min) Glass Hardness: 3H Variable Refresh Rate Technology: Yes Low Blue Light: Hardware and software solution Flicker-Free: Yes Color Gamut: NTSC 80% size (Typ), sRGB 114% size (Typ) Pixel Size: 0.275 mm (H) × 0.275 mm (V) Surface Treatment: Anti-Glare, Hard Coating (3H)
Compatibility
PC Resolution (max): 1920 × 1080 Mac® Resolution (max): 1920 × 1080 Mac® Resolution (min): 1920 × 1080 PC Operating System: Windows 10/11 certified; macOS tested
Connector
VGA: 1 HDMI 1.4: 1 Power In: DC Socket (Center Positive)
Power
Eco Mode (Conserve): 13W Eco Mode (Optimized): 17W Consumption (Typical): 21W Consumption (Max): 24W Voltage: AC 100?240V Stand-by: 0.5W Power Supply: External Power Adaptor
Controls
Physical Controls: Up, Right, Down, Left, Power On Screen Display: Input Select, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu
Operating Conditions
Temperature: 32°F to 104°F (0°C to 40°C) Humidity (Non-Condensing): 20% to 90%
Wall Mount
VESA Compatible: 100 × 100 mm
Input Signal
Frequency Horizontal: RGB Analog: 24?86KHz, HDMI (v1.4): 30?182KHz Frequency Vertical: RGB Analog: 48?75Hz, HDMI (v1.4): 48?144Hz
Video Input
Digital Sync: TMDS ? HDMI (v1.4) Analog Sync: Separate ? RGB Analog
Ergonomics
Tilt (Forward/Back): -5º / 20º
Weight (Imperial)
Net: 6.2 lbs Net Without Stand: 5.5 lbs Gross: 8.8 lbs
Weight (Metric)
Net: 2.8 kg Net Without Stand: 2.5 kg Gross: 4 kg
Dimensions (Imperial) (W × H × D)
Packaging: 23.7 × 16.3 × 4.8 in. Physical: 21.35 × 16.5 × 7.45 in. Physical Without Stand: 21.35 × 12.69 × 1.8 in.
Dimensions (Metric) (W × H × D)
Packaging: 602 × 415 × 122 mm Physical: 542.18 × 419.07 × 189.2 mm Physical Without Stand: 542.18 × 322.4 × 45.6 mm
General
Regulations: CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BIS
Package Contents
ViewSonic VA24G1-H × 1 HDMI Cable (v1.4; Male-Male) × 1 AC/DC Adapter × 1 Quick Start Guide × 1 Power Plug × 1 or 2 (by country)
